Dataset Modeler Layout

Dataset Modeler components#

  • Add Entity Action - Menu for creating new entity or to add already existing entity from different dataset.
  • Modeler Drawer - Menu for saveing, loading and deploying dataset models
  • Model - itself. It is consisted of Entities and Relations
  • Object Menu - Popup menu that allows user to change entity or relation properties

Dataset Modeler Layout#

Load and Save applet

Modeler Drawer#

Modeler drawer is consisted of 3 applets for dataset management. Folder icon action in drawer opens up Load Applet as displayed on picture bellow. Load Applet will display all available datasets and by clicking on load action last saved version for selected dataset will be loaded in to Dataset Modeler.
